Engine
Engine Type
Liquid-cooled, 4-stroke 90 V-twin
Displacement
749 cm
Maximum Power
37.3 kW {51 PS} / 6,750 rpm
Maximum Torque
58.1 N.m {5.9 kgf.m} / 4,750 rpm
Bore x stroke
85 x 66 mm
Ignition
Battery and Coil (Transistorised ignition)
Starting
Electric
Performance & Transmission
Compression ratio
9.3:1
Valve/Induction system
SOHC, 8 valves
Fuel system
Fuel injection: O 36 mm x 2
Fuel capacity
19 litres
Transmission
2-speed automatic with reverse
Final Drive
Shaft 2WD/4WD
Frame & Dimensions
Frame type
Double cradle, high-tensile tubular steel
Dimensions (L x W x H)
2,185 x 1,170 x 1,210 mm
Wheelbase
1,285 mm
Ground Clearance
228 Std Preload setting, 245 max preload setting mm
Curb Mass
318 kg
