Engine Type
Liquid-cooled, 4-stroke In-line 3-cylinder diesel, OHV
Displacement
993 cm3
Maximum Power
17.8 kW {24 PS} / 3,600 rpm
Maximum Torque
52.1 N.m {5.3 kgf.m} / 2,400 rpm
Bore x stroke
74.0 x 77.0 mm
Starting
Electric
Engine
Engine Type
Liquid-cooled, 4-stroke In-line 3-cylinder diesel, OHV
Displacement
993 cm3
Maximum Power
17.8 kW {24 PS} / 3,600 rpm
Maximum Torque
52.1 N.m {5.3 kgf.m} / 2,400 rpm
Bore x stroke
74.0 x 77.0 mm
Starting
Electric
Performance & Transmission
Compression ratio
23.5:1
Fuel system
In-line injection pump
Fuel capacity
30 litres
Transmission
CVT, 2-speed auto, reverse
Final Drive
2WD / 4WD, shaft, Dual-Mode Differential
Frame & Dimensions
Frame type
Tubular double-cradle, high-tensile steel
Dimensions (L x W x H)
3,385 x 1,625 x 1,970 mm
Wheelbase
2,345 mm
Ground Clearance
260 mm
Curb Mass
880 kg
