Engine Type
Air cooled, OHV, 4-stroke single
Displacement
401cm3
Maximum Power
9.9 kW {13 PS} / 4,000 rpm
Maximum Torque
29.0 N•m {3.0 kgf•m} / 2,400 rpm
Bore x stroke
82 x 76 mm
Ignition
Magneto and transistor
Starting
Electric
Engine
Engine Type
Air cooled, OHV, 4-stroke single
Displacement
401cm3
Maximum Power
9.9 kW {13 PS} / 4,000 rpm
Maximum Torque
29.0 N•m {3.0 kgf•m} / 2,400 rpm
Bore x stroke
82 x 76 mm
Ignition
Magneto and transistor
Starting
Electric
Performance & Transmission
Compression ratio
8.6:1
Fuel system
Fuel Injection
Fuel capacity
16 litres
Transmission
CVT, 2 speed auto, reverse
Final Drive
Shaft 2WD/4WD
Frame & Dimensions
Frame type
Tubular double-cradle, high-tensile steel
Dimensions (L x W x H)
2,710 x 1,335 x 1,800 mm
Wheelbase
1,780 mm
Ground Clearance
170 mm
Curb Mass
468 kg
